IP broadcast + speaker
DH-S30C/DH-S40C/DH-S60C
SIP SC series of broadcast speakers
SIP speakers are network broadcast devices based on the SIP protocol that can receive audio streams over the IP network and play them in real-time. They are often used for remote announcements, scheduled broadcasts, and emergency notifications. The standard SIP/ONVIF protocol enables easy integration with most brands in the VoIP and security industries.
Features
IP broadcasting, supports local area networks and the internetSupports video linkage (optional)Supports broadcasting via 3 external input/output channelsSupports 2-channel linkage outputFull-duplex voice communicationHigh-quality speakersPainted aluminum alloy casing, with automotive baking paint process, rust-resistant and more waterproofIP network architecture, capable of crossing network segments and routersMonitoring functionBroadcasting functionMobile APP remote control, calling, video intercom (optional)Supports TCP/IP network broadcasting, scheduled broadcasting, zone broadcasting, real-time broadcasting, alarm broadcasting, can be integrated with emergency broadcasting systems, suitable for public broadcasting scenarios such as campuses, parks, scenic areas, and communities
| Processor | High-performance embedded System-on-Chip (SOC) processor |
| Operating system | Embedded LINUX operating system |
| Rated power | 30W/40W/60W |
| Audio input | Built-in high-sensitivity omnidirectional microphone (optional) |
| Audio Output | Built-in Speaker + 1x LINE OUT |
| Compression Standard | G.711, G.713, GSM, PCM |
| Compression Bitrate | 32KBPS/64KBPS/128KBPS |
| Sound quality | Professional echo and noise reduction (optional) |
| Network | Wired |
| Network Protocol | SIP, TCP/IP, DNP |
| Interconnection Interface | 3 |
| Power Source | DC 12V |
| Power consumption | ≤60W |
| Material | Metal spray paint |
| Dimensions | 110mmX100mmX380mm/480mm/580mm |
| Operating Temperature | -30°C~75°C |
